First Impression
The UN32B adapter is designed for desktop/Laptop PCs that convert 5G/4G/3G WWAN M.2 Socket 2 key B PCIe & USB 3.0 dual bus module to full mini card Rev 2.1 slot.
You can insert your M.2 card (Socket 2 WWAN) such as 5G,4G, LTE cards to this adapter .
|
|
Function
- Allows user to use M.2 Socket 2 WWAN Module to mPCIe Slot in the Desktop or Laptop.
- Supports PCIe & USB 3.0 interface of M.2 Cards (Socket 2 WWAN) such as 5G, 4G, LTE, Mini Card to desktop PC.
- Support Full size mPCIe slot.
|
|
Specifications
- PCIe & USB 3.0 M.2 B key Card to mini card Rev 2.1 adapter.
- M.2 Specification Revision 1.0
- Universal Serial Bus Specification Revision 3.0
- Support 3030/3042/3050/3052 M.2 Card dimension.
- Support M.2 Socket 2 PCIe & USB 3.0 dual bus WWAN Module.
- Support M.2 Socket 2 Key B Card Type.
- Support Dual SIM Card.
|
|
M.2 (NGFF) to mini PCI-E Adapter comparison |
Model Name |
UN32B |
M2BU3S-U3D |
M2BU3S-U2D |
M2BU3S-PU |
M2MU2 |
Function |
M.2 to mini card Rev 2.1 |
M.2 to mini card Rev 2.1 |
M.2 to mini card Rev 2.1 |
M.2 to mini card Rev 2.1 |
M.2 to mPCIe |
Interface |
PCIe & USB 3.0 |
USB 3.0 |
USB 2.0 |
PCIe 2x or SATA |
USB 2.0 |
M.2 SPEC |
Socket 2 PCIe & USB3.0 dual bus WWAN |
Socket 2 SSIC-based WWAN |
Socket 2 SSIC-based WWAN |
Socket 2 |
Socket 2 SSIC-based WWAN |
Application |
5G / 4G / 3G / CDMA / LTE / GPS module |
5G / 4G / CDMA / LTE / GPS module |
5G / 4G / CDMA / LTE / GPS module |
PCIe 2x or SATA SSD module |
5G / 4G / CDMA / LTE / GPS module |
Module KEY |
B |
B |
B |
B |
B |
Support Card Type |
3030/3042/3050/3052 |
2242,50,52 / 3042,50,52 |
2242,50,52 / 3042,50,52 |
2242,50,52 / 3042,50,52 |
2230/2242/3030/3042 |
Photo |
|
|
|
|
|
M.2 (NGFF) to mini PCI-E Adapter comparison |
Model Name |
MN25A |
M2MP1-A |
M2MP1-E |
M2MP3-A |
M2MP3-E |
Function |
M.2 to mPCIe |
M.2 to mPCIe |
M.2 to mPCIe |
M.2 to mPCIe |
M.2 to mPCIe |
Interface |
PCIe & USB2.0 |
PCIe & USB2.0 |
PCIe & USB2.0 |
PCIe & USB2.0 |
PCIe & USB2.0 |
M.2 SPEC |
Socket 1
First PCIe Lane |
Socket 1
First PCIe Lane |
Socket 1
First PCIe Lane |
Socket 1
Second PCIe Lane |
Socket 1
Second PCIe Lane |
Application |
WiFi+BT module |
WiFi+BT module |
WiFi+BT module |
WiFi+BT module |
WiFi+BT module |
Module KEY |
E |
A |
E |
A |
E |
Support Card Type |
2230 |
2230/2242/3030/3042 |
2230/2242/3030/3042 |
2230/2242/3030/3042 |
2230/2242/3030/3042 |
Photo |
|
|
|
|
|
mini PCI-E to M.2 (NGFF) Adapter comparison |
Model Name |
NM51A |
NM61A-P01 |
NM61A-U3 |
|
|
Function |
mPCIe to M.2 |
mPCIe to M.2 |
mPCIe to M.2 |
|
|
Interface |
PCIe & USB2.0 |
PCIe |
USB3.0 |
|
|
M.2 SPEC |
Socket 1 First PCIe Lane |
Socket 2 First PCIe Lane |
Socket 2
USB3.0 |
|
|
Application |
WiFi+BT module |
PCIe Interface module |
USB Interface module |
|
|
Module KEY |
A E |
B M |
B M |
|
|
Support Card Type |
3042/3050/3052/3060 |
3042、50、52、60、80 |
3042、50、52、60、80 |
|
|
Photo |
|
|
|
|
|
|
Package Content
UN32B-F1 E11
Unit price: USD 70. |
|
|
|
UN32B PCBA E11
M.2 key B PCIe & USB 3.0 dual bus module to mini card Rev 2.1 Adapter x1
with Dual SIM Card slot
|
Y09-U10-060
( 9Pin 1.5 Pitch Header to Type A USB3.0 cable 60cm) x1
|
Screw x4
|
Flat-Head Screw x2
|
UN32B PCBA E11
Unit price: USD 50. |
|
|
|
UN32B PCBA E11
M.2 key B PCIe & USB 3.0 dual bus module to mini card Rev 2.1 Adapter x1
with Dual SIM Card slot
|
Screw x4
|
Flat-Head Screw x2
|
|
Y09-U10-060
Unit price: USD 20. |
|
|
|
Y09-U10-060
( 9Pin 1.5 Pitch Header to Type A USB3.0 cable 60cm) x1
|
|
|
|
|
