Home > Product > M.2 Interface > NM51A
mPCIe Module to M.2 A E key Adapter






First Impression

名稱 (Name) : NM51A
簡介 (Summary) : mPCIe (PCIe+USB) to M.2 A E key adapter
界面 (Interface):  M.2 A E key side: PCIe + USB (Socket 1)
mPCIe side : mini PCI-E (PCIe+USB)


  • Allows user to use mPCIe Module to M.2 A E key Slot in the Desktop or Laptop.
  • Supports system bus interface: PCIe & USB.
  • No drivers needed for this mini PCI-E Card to M.2 A E key Adapter


  • M.2 Specification Revision 1.0
  • PCI Express base Specification 1.1 (Up to 2.5Gpbs)
  • USB Specification Revision2.0
  • Support Full size and half size mPCIe card
  • Support 3042/3050/3052/3060 M.2 Card dimension slot.

    System Requirement

  • M.2 A E key slot
  • Windows or Linux

mini PCI-E to M.2 (NGFF) Adapter comparison
Model Name NM51A NM61A-P01 NM61A-U3
Function mPCIe to M.2 mPCIe to M.2 mPCIe to M.2
Interface PCIe & USB2.0 PCIe USB3.0
M.2 SPEC Socket 1
First PCIe Lane
Socket 2
First PCIe Lane
Socket 2
Application WiFi+BT module PCIe Interface module USB Interface module
Module KEY A E B M B M
Support Card Type 3042/3050/3052/3060 3042、50、52、60、80 3042、50、52、60、80


NM51A-P01 E11
Unit price: USD 50.
NM51A-P01 E11
mPCIe Module to M.2 A E key Adapter x1
Screw x4
