M2MU2
M.2 (NGFF) to mini PCI-E Adapter







Brief Taiwan 1 Taiwan 2 China
Compatibility List Taiwan 1 Taiwan 2 China
Buy It Now


First Impression


M.2 stands for Next Generation Form Factor which is invented for PCI-SIG by Intel® and it is developed for flat and high-efficiency equipment such as Ultrabook™ or Tablet PCs. It is a natural transition from the Mini Card and Half Mini Card to a smaller form factor in both size and volume which supports multiple function add-in cards/modules including: Wi-Fi, Bluetooth, global navigation satellite systems, near field communication, Hybrid digital radio, wireless gigabit alliance (WiGig), wireless wide area network and solid-state storage devices. Also adds functionality to USB 3.0, display Port, SDIO and SSD-PCIe
The M2MU2 adapter is designed for desktop/Laptop PCs that convert 3G wireless M.2 Card to full/half mini card slot.
 You can insert your M.2 card (Socket 2 SSIC-base WWAN) such as GSM, HSPA(3.5G), GPS, LTE cards to this adapter then plug to USB port through USB cable.



    Function


  • Allows user to use M.2 Socket SSIC-based WWAN Module to mPCIe Slot in the Desktop or Laptop.
  • Supports USB interface of M.2 Cards (Socket 2 SSIC-base WWAN) such as 2G GSM, GPRS, 3G,CDMA, WLAN,WWLAN, HSPA MODEM , GPS, 4G WiMAX, LTE, Mini Card to desktop PC.
  • Support Full size and half size mPCIe slot

    Specifications


  • USB M.2 Card to mPCIe adapter.
  • M.2 Specification Revision 0.9
  • Universal Serial Bus Specification Revision 2.0
  • Support 2230/2242 M.2 Card dimension.
  • Support M.2 Socket SSIC-based WWAN Module.
  • Support M.2 Key B Card Type.

    System Requirement


  • Mini PCI-E slot
  • Windows 2000, XP, Vista 32/64, Windows 7, Windows 8 or Linux



M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name UN32B M2BU3S-U3D M2BU3S-U2D M2BU3S-PU M2MU2
Function M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mPCIe
Interface PCIe & USB 3.0 USB 3.0 USB 2.0 PCIe 2x or SATA USB 2.0
M.2 SPEC Socket 2 PCIe & USB3.0 dual bus WWAN Socket 2 SSIC-based WWAN Socket 2 SSIC-based WWAN Socket 2 Socket 2 SSIC-based WWAN
Application 5G / 4G / 3G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module PCIe 2x or SATA SSD module 5G / 4G / CDMA / LTE / GPS module
Module KEY B B B B B
Support Card Type 3030/3042/3050/3052 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2230/2242/3030/3042

M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name MN25A M2MP1-A M2MP1-E M2MP3-A M2MP3-E
Function M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe
Interface PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0
M.2 SPEC Socket 1
First PCIe Lane
Socket 1
First PCIe Lane
Socket 1
First PCIe Lane
Socket 1
Second PCIe Lane
Socket 1
Second PCIe Lane
Application WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module
Module KEY E A E A E
Support Card Type 2230 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042

mini PCI-E to M.2 (NGFF) Adapter comparison
Model Name NM51A NM61A-P01 NM61A-U3
Function mPCIe to M.2 mPCIe to M.2 mPCIe to M.2
Interface PCIe & USB2.0 PCIe USB3.0
M.2 SPEC Socket 1
First PCIe Lane
Socket 2
First PCIe Lane
Socket 2
USB3.0

Application WiFi+BT module PCIe Interface module USB Interface module
Module KEY A E B M B M
Support Card Type 3042/3050/3052/3060 3042、50、52、60、80 3042、50、52、60、80



Package Content


M2MU2-S
Unit price: USD 56.

M2MU2-S
M.2 (NGFF) to mini PCI-E Adapter x1
Screw x2
Flat-Head Screw x1





M2MU2
Unit price: USD 50.

M2MU2
M.2 (NGFF) to mini PCI-E Adapter x1
Screw x2
Flat-Head Screw x1
