ホーム > 製品情報 > M.2 (NGFF)系製品 > M2BU3 Series
  M2BU3
M.2 key B USB 3.0 to mini card Rev 2.1 アダプタ




Brief Taiwan 1 Taiwan 2 China
Buy It Now



M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name UN32B M2BU3S-U3D M2BU3S-U2D M2BU3S-PU M2MU2
Function M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mPCIe
Interface PCIe & USB 3.0 USB 3.0 USB 2.0 PCIe 2x or SATA USB 2.0
M.2 SPEC Socket 2 PCIe & USB3.0 dual bus WWAN Socket 2 SSIC-based WWAN Socket 2 SSIC-based WWAN Socket 2 Socket 2 SSIC-based WWAN
Application 5G / 4G / 3G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module 5G / 4G / CDMA / LTE / GPS module PCIe 2x or SATA SSD module 5G / 4G / CDMA / LTE / GPS module
Module KEY B B B B B
Support Card Type 3030/3042/3050/3052 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2230/2242/3030/3042

M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name MN25A M2MP1-A M2MP1-E M2MP3-A M2MP3-E
Function M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe
Interface PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0
M.2 SPEC Socket 1
First PCIe Lane		 Socket 1
First PCIe Lane		 Socket 1
First PCIe Lane		 Socket 1
Second PCIe Lane		 Socket 1
Second PCIe Lane
Application WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module
Module KEY E A E A E
Support Card Type 2230 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042

mini PCI-E to M.2 (NGFF) Adapter comparison
Model Name NM51A NM61A-P01 NM61A-U3
Function mPCIe to M.2 mPCIe to M.2 mPCIe to M.2
Interface PCIe & USB2.0 PCIe USB3.0
M.2 SPEC Socket 1
First PCIe Lane		 Socket 2
First PCIe Lane		 Socket 2
USB3.0
Application WiFi+BT module PCIe Interface module USB Interface module
Module KEY A E B M B M
Support Card Type 3042/3050/3052/3060 3042、50、52、60、80 3042、50、52、60、80



    Function

  • Allows user to use M.2 Socket SSIC-based WWAN Module to mPCIe Slot in the Desktop or Laptop.
  • Supports USB 3.0 interface of M.2 Cards (Socket 2 SSIC-base WWAN) such as 5G,4G,CDMA, WLAN,WWLAN, HSPA MODEM , GPS, LTE, Mini Card to desktop PC.
  • Support Full size and half size mPCIe slot

    Specifications

  • USB 3.0 M.2 B key Card to mini card Rev 2.1 adapter.
  • M.2 Specification Revision 1.0
  • Universal Serial Bus Specification Revision 3.0
  • Support 2230/2242 M.2 Card dimension.
  • Support M.2 Socket SSIC-based WWAN Module.
  • Support M.2 Key B Card Type.

    System Requirement

  • Mini PCI-E slot support mini card Specification Revision 2.1



M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name UN32B M2BU3S-U3D M2BU3S-U2D M2BU3S-PU M2MU2
Function M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mini card Rev 2.1 M.2 to mPCIe
Interface PCIe & USB 3.0 USB 3.0 USB 2.0 PCIe 2x or SATA USB 2.0
M.2 SPEC Socket 2 PCIe & USB3.0 dual bus WWAN Socket 2 SSIC-based WWAN Socket 2 SSIC-based WWAN Socket 2 Socket 2 SSIC-based WWAN
Application 5G / 4G / 3G / CDMA / LTE / GPS module 4G / 3G / CDMA / LTE / GPS module 4G / 3G / CDMA / LTE / GPS module PCIe 2x or SATA SSD module 4G / 3G / CDMA / LTE / GPS module
Module KEY B B B B B
Support Card Type 3030/3042/3050/3052 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2242,50,52 / 3042,50,52 2230/2242/3030/3042

M.2 (NGFF) to mini PCI-E Adapter comparison
Model Name M2MP1-A M2MP1-E M2MP3-A M2MP3-E M2MS1
Function M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mPCIe M.2 to mSATA
Interface PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 PCIe & USB2.0 SATA
M.2 SPEC Socket 1
First PCIe Lane		 Socket 1
First PCIe Lane		 Socket 1
Second PCIe Lane		 Socket 1
Second PCIe Lane		 Socket 2 SATA-based
Application WiFi+BT module WiFi+BT module WiFi+BT module WiFi+BT module SATA SSD module
Module KEY A E A E B / B+M
Support Card Type 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042 2230/2242/3030/3042

mini PCI-E to M.2 (NGFF) Adapter comparison
Model Name NM51A NM61A-P01 NM61A-U3
Function mPCIe to M.2 mPCIe to M.2 mPCIe to M.2
Interface PCIe & USB2.0 PCIe USB3.0
M.2 SPEC Socket 1
First PCIe Lane		 Socket 2
First PCIe Lane		 Socket 2
USB3.0
Application WiFi+BT module PCIe Interface module USB Interface module
Module KEY A E B M B M
Support Card Type 3042/3050/3052/3060 3042、50、52、60、80 3042、50、52、60、80

Package Content



M2BU3S-U3D
販売価格: USD 50.

M2BU3S-U3D
M.2 key B USB 3.0 module to mini card Rev 2.1 Adapter x1
with Dual SIM Card slot
 Screw x4
 Flat-Head Screw x2

 Washer x2



M2BU3S-U2D
販売価格: USD 47.

M2BU3S-U2D
M.2 key B USB 2.0 module to mini card Rev 2.1 Adapter x1
with Dual SIM Card slot
Screw x4
 Flat-Head Screw x2

 Washer x2





M2BU3S-PU
販売価格: USD 47.

M2BU3S-PU
M.2 PCIe x2 module to mini card Rev 2.1 Adapter x1
 Screw x4
 Flat-Head Screw x2

 Washer x2



Buy Related Items

M2MP1
M2MP1-E
M2MP3-A
M2MP3-E
