Home > Product > mini SATA interface > PM1092R

  PM1092R
(Dual SATA to mini-SATA RAID Adapter)





Brief Taiwan 1 Taiwan 2 China
Dimension Taiwan 1 Taiwan 2 China
Schematic Taiwan 1 Taiwan 2 China
Web Shop


First Impression


PM1092R adapter enables two SATA device to mSATA by RAID function in the laptop PC or desktop PC. Once installed, the SATA device in some RAID mode with faster or more reliable RAID functions, low power consumption, fast access time and completely shock resistant.





    Function


  • Allows user to use standard SATA device to mSATA in the Desktop or Laptop
  • RAID mode : JBOD (Port Multiplier ), RAID0 (Striping/Fast), RAID1(Mirror/Safe), Span (Big)
      GUI JBOD RAID0 RAID1 Span
    J1 x 1 1 0 0
    J2 1 0 0 0 0
    J3 x 1 0 1 0
  • Support Hi-Speed SATA3 / 6Gbps mass storage interface.
  • Transparent to the operating system and does not require any software drivers
  • Dimension: DxWxH : 30 x 26.8 x 11.4 mm

    System Requirement


  • System supporting mSATA slot



Web Shop



PM1092R
Contact Sales

PM1092R
(Dual SATA to mini-SATA RAID Adapter) x1
Metal Baffle
(Half to Full miniCard Bracket) x1
Screw x4



Buy Related Items


SSDMC
SSDMB
MP3S
SSDMR
