  SSDMC
(mini-SATA to SATA Adapter)


Introduction:
SSDMC adapter enables using of mini-SATA SSD as a direct replacement for the 2.5” HDD in the notebook. Once installed, the mSATA SSD behaves like the 2.5”HDD with low power consumption, fast access time and completely shock resistant



      Function


  • Allows user to use standard SATA-IO mSATA SSD to SATA hard drive in the Desktop or Laptop
  • Support Hi-Speed SATA3 / 6Gbps mass storage interface.
  • Transparent to the operating system and does not require any software drivers
  • SSDMC V1.5 Support devslp (Device Sleep)

Notice

The Products only support mSATA SSD Card ,Can't support Eee PC SSD Card(mPCIe SSD Card) and Apple macbook air SSD Card.
Please check compatibility list for detail.
The SSDMC Products only support 2.5" HDD Dimension.



System Requirements:
DOS, Windows XP, Vista, Windows 7, Server 2008
Linux, Mac



SSDMC
SSDMC module SSDMC V1.5
Transmission performance test report
Mainboard Model: Gigabyte GA-Z77MZ-D3H TH     System : win7 32 bit
CPU: intel(R) Core (TM)i5- 3570K @ 3.4GHz / 3.8GHz
RAM : 8GB      Graphic Card: Intel HD Graphic 2500
mSATA SSD: ADATA XPG SX300 ASX300S3-128GM-C 128GB
SSDMC V1.3
Unit price: USD 56.
SSDMC V1.3
(mini-SATA to 2.5” SATA hard drive frame kit) x1
Screw x2

Notice

The Products only support mSATA SSD Card ,Can't support Eee PC SSD Card(mPCIe SSD Card) and Apple macbook air SSD Card.
Please check compatibility list for detail.
The SSDMC Products only support 2.5" HDD Dimension.
SSDMC V1.5
Unit price: USD 80.
SSDMC V1.5
(mini-SATA to 2.5” SATA hard drive frame kit) x1
Screw x2

Notice

The Products only support mSATA SSD Card ,Can't support Eee PC SSD Card(mPCIe SSD Card) and Apple macbook air SSD Card.
Please check compatibility list for detail.
The SSDMC Products only support 2.5" HDD Dimension.


MP2S, SSDMA, SSDMB,SSDMC,SSDMC-U for SSD minicard comparison                2011/Apr/21
Functions comparison
MP2S ver 1.0b
SSDMA
SSDMB
SSDMC
SSDMC-U
Interface
PATA / SATA
USB2.0
USB3.0
SATA
SATA
EeePC PATA SSD minicard support
Yes
Yes
No
No
No
EeePC SATA SSD minicard support
Yes
Yes
No
No
No
mini-SATA SSD minicard support
No
No
Yes
Yes
Yes
Access LED
Yes
Yes
Yes
No
No
Appearance
Add-on card
Enclosure
Enclosure
2.5”HDD
Add-on card
2.5”HDD
Add-on card
Mini USB2.0 connector
MiniCard dimension support
Full/Custom
Full
Full
Full
Full

Notice:
Almost mini-SATA SSD haven’t USB interface. Please check your mini-SATA SSD is supported for USB interface. Otherwise SSDMC-U USB function should invalid.
The SSDMC / SSDMC-U Products only support 2.5" HDD Dimension.




Documents Download
SSDMC V1.3 Brief   Taiwan   Taiwan 2 Mirror
SSDMC V1.0 Brief   Taiwan   Taiwan 2 Mirror
Dimension   Taiwan   Taiwan 2 Mirror
Schematic   Taiwan   Taiwan 2 Mirror
Compatibility List  Taiwan 1  Taiwan 2 Mirror
Comparison List  Taiwan 1   Taiwan 2 Mirror
