Home > Product > Extender Board > P34SF-SATA

    P34SF-SATA
(SATA to Mini SATA Extender)


Introduction:
P34SF-SATA Extender is a debug and test tool to extend SATA port from Mini SATA (mSATA). Design the FFC (Flat Flexible Cable) cable for flexible use.
Not only for Full-size Mini SATA slot but also Half-size Mini SATA by removing extra Full-size extensions.
The extender is designed to minimize the signal degradation effects of the extender by proven design techniques. It’s also a powerful tool for engineers and factory tests.

P34SF-SATA (KZ-B34-SATA) :FFC cable length 20cm ,Width 6mm, Thickness 0.1mm



    Specification:

  • Serial ATA I/O: Serial ATA Revision 3.1 Compliant

    Requirements:

  • mSATA slot

    Function:

  • Allows user to use standard SATA hard device to SATA-IO mSATA slot in the Desktop or Laptop
  • Transparent to the operating system and does not require any software drivers
  • FFC Cable: Width 6mm, Thickness 0.1mm

Notice:
This adapter is engineering test tools. NOT for home or office use.
The Products just only support mSATA slot, Can’t support PCI express minicard, Can’t support Apple MacBook Air SSD Card.





P34SF-SATA
Unit price: USD 80.
P34SF-SATA
(SATA to Mini SATA Extender) x1
with
FFC0510P-020A (FFC cable 20cm) x1
Screw x2


Documents Download
Brief   Taiwan   Taiwan 2 Mirror   China Mirror
Dimension   Taiwan   Taiwan 2 Mirror   China Mirror
3D Model  Taiwan  Taiwan 2 Mirror  China Mirror
Schematic   Tawan   Taiwan 2 Mirror   China Mirror
Selection Guide   Tawan   Taiwan 2 Mirror   China Mirror
