Home > Product > Extender Board > P26S-P26F

  P26S-P26F
(ExpressCard34 to MiniCard Extender)


Introduction:
P26S-P26F Extender is a debug andtesttool to extend ExpressCard slot from MiniCard (mPCIe) slot. Design the FFC (Flat Flexible Cable) cable for flexible use.
Not only for Full-size MiniCard adapter but also Half-size MiniCard by removing extra Full-size extensions.
The extender is designed to minimize the signal degradation effects of the extender by proven design techniques.
It’s also a powerful tool for engineers and factory tests.

P26S-P26F FFC cable Length= 30cm

    Specification:

  • ExpressCard Standard Release 2.0 (PCMCIA)
  • PCI Express base Specification 2.0 (Up to 5Gpbs)
  • USB Specification, Release 2.0 Hi-Speed (Up to 480Mbps)
  • System Management Bus (SMBus) Specification, Version 2.0
  • PCI Express Card Electromechanical (CEM) Specification 2.0
  • Power Supply: 3.3V & 1.5V
  • FFC Cable: Width 26mm, Thickness 0.1mm

    Function:

  • Easy Installation, Plug and Play; Enable hot-plug and hot-swap
  • No drivers needed for this MiniCard to ExpressCard Adapter
  • Support ExpressCard 34 cards.
  • Push-Pull TypeConnector for stable installation
  • Support Windows 2000/Server 2003/XP & XP 64-bit/Vista & Vista 64-bit/ 7 & 7 64-bit
  • Supports both PCI Express based and USB 2.0 based ExpressCard
  • Supports USB 2.0 480 Mb/s data rate
  • Miscellaneous: CLKREQ#, WAKE#, PERST#

    Requirements:

  • PCI express mini card slot

    Warning:

  • Do NOT hot-swap ExpressCARD adapter to avoid the possibility of data lost!
    Please apply “safety removal” before removing ExpressCard.
    Especially hot-swap of PCIe type Express Card is not supported.
  • If MiniCard slot on the host does not support PCIe or USB interface, ExpressCard with the interface can not be supported.
  • Maximum speed of PCIe2.0 (5Gbps) is not guaranteed.




P26S-P26F
Unit price: USD 70.

P26S x1
P26F x1
FFC0536P-030B (FFC cable 30cm) x1

Screw x2


Documents Download
Brief   Taiwan   Taiwan 2 Mirror   China Mirror
Selection Guide   Tawan   Taiwan 2 Mirror   China Mirror
