USB3380EVB  (USB3380 Evaluation Board)


Introduction:
The USB 3380 is a PCI Express Gen 2 to USB 3.0 SuperSpeed Peripheral Controller. It features one PCI Express Gen 2 x1 port and one USB 3.0 SuperSpeed client port. The USB 3380 provides a matching bandwidth at 5 GT/s between the PCI Express Gen 2 bus and the USB 3.0 SuperSpeed bus. The controller can easily add a USB 3.0 client port to an existing PCI Express system, as well as convert an existing PCI Express function (endpoint) to a USB 3.0 product. The USB 3380 can configure the PCI Express port as one x1 upstream port or one x1 downstream port. The flexibility allows different system configurations to achieve the maximum performance of the product.

    Specification

    USB 3.0 Client Interface

  • USB 3.0 Specification.
  • 1 upstream port.
  • Supports SuperSpeed, Hi-Speed, Full-Speed modes.
  • Four Descriptor-based DMA channels for automatic data transfers.
  • Supports USB Duet® Technology.
  • USB Auto-Enumeration Technology
  • Support for Bulk, Isochronous, and Interrupt Endpoints.
  • USB Power Management USB 3.0 link power management states: U0, U1, U2, U3
  • USB 2.0 link power management states: L0, L1, L2

    PCI Express Interface

  • PCI Express Gen 2 (5Gbps)
  • Electrical Compliance to PCI Express Base Specification r2.0
  • PCIe interface and integrated root complex provides two configurations:
    one x1 upstream port
    one x1 downstream port
  • PCI Express Power Management All link power management states: L0, L0s, L1, L2/L3 Ready, and L3
    Device states: D0 and D3(hot & cold)
    Vaux, Wake#, Beacon support
  • 256 byte maximum payload size
  • ExpressCard 2.0 compliance


Note:
We can not provide driver software and technical support, to get RDK and technical support services,

Please contact PLX product sales representative or distributor.
https://www.broadcom.com/products/pcie-switches-bridges/usb-pci/usb-controllers/usb3380#overview


Applications:

Target applications for the USB3380EVB adapter as a PCI Express endpoint include PCs, servers, docking stations, printers, and PCI Express embedded systems.
Add a USB 3.0 Client Port to PCI Express-Based Systems
The USB 3380 can be used to easily add a USB 3.0 client port to any PCI Express based embedded system.
As a PCI Express endpoint, the USB 3380’s Standard PCI Express interface connects directly to any PCI Express bus.

Add a USB 3.0 Client Port to ExpressCard-Based Systems
The USB 3380 can be used to easily add a USB 3.0 client port to any ExpressCard based embedded system.


Add a USB 3.0 Client Port to PCI Express-Based Systems
The USB 3380 can be used to easily add a USB 3.0 client port to any PCI Express based embedded system.
As a PCI Express endpoint, the USB 3380’s Standard PCI Express interface connects directly to any PCI Express bus.

OPTION



Buy It Now

Note:
We can not provide driver software and technical support, to get RDK and technical support services,

Please contact PLX product sales representative or distributor.
https://www.broadcom.com/products/pcie-switches-bridges/usb-pci/usb-controllers/usb3380#overview
USB3380EVB
Unit price: USD 220.
USB3380EVB
(mini PCI Express to USB 3.0 Adapter) x1
Screw x2


OPTION

PE3B
Unit price: USD 130.
PE3B
( Mini Card to ExpressCard Adapter ) x1
Y05-U17-060
(USB A Male to DC Power Cable) x1
Screw x2



Documents Download
Brief  Taiwan 1   Taiwan 2 Mirror   China Mirror
USB3380EVB
Schematic
 Taiwan 1   Taiwan 2 Mirror   China Mirror
USB3380-AB EVK-RC
Schematic
 Taiwan 1   Taiwan 2 Mirror   China Mirror
