  SSDM2
(M.2 SSD to SATA Adapter)





Brief Taiwan 1 Taiwan 2
Dimension Taiwan 1 Taiwan 2
Schematic Taiwan 1 Taiwan 2
3D Model Taiwan 1 Taiwan 2
M.2 (NGFF) Products List table Taiwan 1 Taiwan 2
Web-shop


First Impression


SSDM2adapter enables using of M.2 SSD as a direct replacement for the 2.5” HDD in the notebook. Once installed, the M.2 SSD behaves like the 2.5”HDD with low power consumption, fast access time and completely shock resistant.



    Function


  • Allows user to use M.2 SSD asstandard SATASSDin the Desktop or Laptop
  • Support M.2 Socket 2 SSDtype 2230, type 2242, type 2260
  • Support M.2 SSD with Key B including Key B+M
  • Support Hi-Speed SATA3/ 6Gbps mass storage interface.
  • Transparent to the operating system and does not require any software drivers
  • Dimension (2.5” Enclosure): D x W x H = 100 x 70 x 8 (mm)
  • Module: Support Low Profile / Standard Height PCIe Slot

    System Requirement


  • System supporting SATA 7pin data port and SATA 15pin power.

Web-shop



SSDM2
Unit price: USD 120.
SSDM2
(M.2 SSD to SATA Adapter) x1
Flat-Head Screw x1



SSDM2 module
Unit price: USD 100.
SSDM2 module
(M.2 SSD to SATA Adapter) x1
JP0155
( Standard Height PCI express bracket ) x1
Flat-Head Screw x1


Buy Related Items


M2S-C
M2S-C

M.2 (NGFF)
