  NB96M
LTE Cat M1 & Cat NB1 & EGPRS Mini PCIe Module

Introduction of Products


NB96M Mini PCIe is a series of LTE Cat M1/Cat NB1/EGPRS module adopting standard PCI Express® Mini Card form factor (Mini
PCIe). It offers a maximum data rate of 375Kbps downlink and 375Kbps uplink, and features ultra-low power consumption.
With a cost-effective SMT form factor of 51.0mm × 30.0mm × 4.9mm and high integration level, BG96 enables integrators
and developers to easily design their applications and take advantage from the module’s low power consumption and
mechanical intensity.
A rich set of Internet protocols, industry-standard interfaces and abundant functionalities (USB drivers for Windows
7/8/8.1/10, Linux, etc.) extend the applicability of the module to a wide range of M2M applications such as wireless POS,
smart metering, tracking, etc.

        Key Benefits


  • LTE Cat M1/Cat NB1/EGPRS module with ultra-low power consumption
  • Standard PCI Express® Mini Card form factor (Mini PCIe) ideal for
    manufacturers to easily integrate wireless connectivity into their devices
  • Easy migration from Quectel GSM/GPRS, UMTS/HSPA and LTE modules
  • Fast time-to-market: reference designs, evaluation tools and timely
    technical support minimize design-in time and development efforts
  • Robust mounting and interfaces





Product Name LTE Cat M1 & Cat NB1 & EGPRS Mini PCIe Module
Model Name NB96M
Version mini PCI-E
Product Picture
產品圖像
製品画像
Price
價格
価格
Contact Sales



Variant for the Global

NB96M Mini PCIe
Cat M1/Cat NB1: LTE FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/
B19/B20/B26/B28
LTE TDD: B39 (For Cat M1 Only)
EGPRS:
850/900/1800/1900MHz
Data
Cat M1: Max. 375Kbps (DL), Max. 375Kbps (UL)
Cat NB1: Max. 32Kbps (DL), Max. 70Kbps (UL)
EDGE: Max. 296Kbps (DL), Max. 236.8Kbps (UL)
GPRS: Max. 107Kbps (DL), Max. 85.6Kbps (UL)
Voice
VoLTE (For Cat M1 Only. Support Realtek ALC 5616 Codec by Default Firmware)
SMS
Point-to-point MO and MT
SMS Cell Broadcast
Text and PDU Mode
Interfaces
USB 2.0 with High Speed up to 480Mbps
Digital Audio through PCM (Optional)
1.8V/3.0V (U)SIM Card Interface
LED_WWAN# for Network Status Indication
W_DISABLE# for Disabling RF Function
UART × 1
PERST# for Module Resetting
I2C × 1
Enhanced Features
GNSS (Optional): GPS, GLONASS, BeiDou/Compass, Galileo, QZSS
Firmware Upgrade: via USB interface
DFOTA: Delta Firmware Upgrade Over the Air
Processor: ARM A7 Processor, with 3MB Flash and 3MB RAM Available for Users
Electrical Characteristics
Output Power: Max. Power: 23dBm
Consumption @LTE Cat M1 (Typical): Standby State: TBD
Sleep State: TBD
LTE Connected Mode (Avg.): TBD
Consumption @LTE Cat NB1 (Typical): Standby State: TBD
Sleep State: TBD
LTE Connected Mode (Avg.): TBD
Sensitivity: TBD
Software Features
USB Serial Driver: Windows 7/8/8.1/10, Windows CE 5.0/6.0/7.0,
Linux 2.6/3.x/4.1~4.14, Android 4.x/5.x/6.x/7.x
RIL Driver*: Android 4.x/5.x/6.x/7.x
NDIS Driver*: Windows 7/8/8.1/10
ECM Driver*: Linux 2.6/3.x/4.1~4.14
Gobinet Driver*: Linux 2.6/3.x/4.1~4.14
QMI_WWAN Driver*: Linux 3.x(3.4 or later)/4.1~4.14
Protocols: PPP/TCP/UDP/SSL/TLS/FTP(S)/HTTP(S)/NITZ/ PING/MQTT
General Features
3GPP E-UTRA Release 13
Temperature Range: -40°C ~ +80°C
Dimensions: 51.0mm × 30.0mm × 4.9mm
Approx. 8g
Mini PCIe Package
Supply Voltage: 3.0V~3.6V, 3.3V Typ.
3GPP TS27.007, 3GPP TS 27.005 and Quectel
Enhanced AT Commands
Approvals
CE*/GCF* (Europe)
FCC*/PTCRB*/Verizon*/AT&T*/T-Mobile* (North
America)
RCM*/Telstra* (Australia)
IFETEL* (Mexico)
IC*/BELL*/Telus* (Canada)
JATE*/TELEC*/KDDI*/Softbank (Japan)
KC*/SKT * (Korea)
CCC* (China)
