Intel® Dual Band Wireless-AC 7260


Intel® Dual Band Wireless-AC 7260
802.11ac, Dual Band, 2x2 Wi-Fi + Bluetooth 4.0*

Ultra Wi-Fi. Ultra Features. Ultra Connected Experience
The Intel® Dual Band Wireless-AC 7260 802.11ac, dual band, 2x2 Wi-Fi + Bluetooth* adapter lets you move at the speed of life with faster speeds (up to 867 Mbps1), higher capacity, broader coverage and longer battery life. Combined with 4th Gen Intel ® Core™ processors and exceptional Intel wireless innovations, the Intel® Dual Band Wireless-AC 7260 dramatically reshapes your connected experience at home, work or on the go.

  • 7260HMW
Product Name Intel® Dual Band Wireless-AC 7260
Model Name 7260HMW    (7260.HMWG,923252)
Version mini PCI-E
Product Picture
產品圖像
製品画像
Price
價格
価格
Minimum Order Quantity: 100PCS
100PCS price:USD 2800.
Related Items
相 關 配 件
RF21008A
RP-SMA IPX 8cm
US$ 3.
RF11008A
SMA IPX 8cm
US$ 3.



Intel® Dual Band Wireless-AC 7260 Technical Specifications
More Speed Better Coverage Larger Capacity 802.11ac, Dual Band, 80MHz, 2x2 Delivers dramatically faster Wi-Fi speeds (up to 867 Mbps) than 802.11n, with more bandwidth per stream 433 Mbps), more capacity for more users (extended channel bonding 80MHz), broader coverage and better battery life (more data transmit efficiencies reduce power consumption).
Bluetooth 4.0* Smart Ready (Low Energy) Dual mode Bluetooth 4.0* connects to the newest low energy Bluetooth* products as well as your familiar devices, such as headsets, keyboard, mice and more.
Intel® Power Optimizer
Optimized power mode during periods of inactivity saves battery life for greater mobility and convenience.
Operating Temperature (Adapter Shield) 0º to +80° C
Humidity Non-Operating 50% to 90% RH non-condensing (at temperatures of 25°C to 35°C)
Operating Systems Microsoft Windows 7*, Microsoft Windows 8*, Linux* (most features not available on Linux)
Wi-Fi Alliance Wi-Fi CERTIFIED* for 802.11ac, Wi-Fi CERTIFIED* a/b/g, Wi-Fi CERTIFIED* n, WMM*, WPA*, WPA2*, and WPS, WPS 2.0, Protected Management Frames, Wi-Fi Direct* for peer to peer device connections
IEEE WLAN Standard IEEE 802.11abgn, 802.11ac, 802.11d, 802.11e, 802.11i, 802.11h, 802.11w
Architecture Infrastructure and SoftAP; Supports simultaneous Client and SoftAP modes
Roaming Supports seamless roaming between respective access points (802.11b, 802.11g, 802.11a/b/g, 802.11a/b/g/n, and 802.11ac)
Bluetooth Dual Mode Bluetooth* 2.1, 2.1+EDR, 3.0, 3.0+HS, 4.0 (BLE)
Authentication WPA and WPA2, 802.1X (EAP-TLS, TTLS, PEAP, LEAP, EAP-FAST), EAP-SIM, EAP-AKA
Authentication Protocols PAP, CHAP, TLS, GTC, MS-CHAP*, MS-CHAPv2
Encryption 64-bit and 128-bit WEP, AES-CCMP, TKIP
Wi-Fi Direct* Encryption and Authentication WPA2, AES-CCMP
Product Safety UL, C-UL, CB (IEC 60950-1)
Management Frame Protection 802.11w (WFA- Protected Management Frames)
