USBMI Series
Wireless USB Mini Card Adapter
|
|
|
First Impression
USBMI Introduction:
The USBMI adapter is designed for desktop PCs that convert Mini-Card to USB port.
You can insert your USB type minicard such as HSPA(3.5G), GPS, 802.11a/b/g to this adapter then plug to USB port through USB cable.
Standard SIM card connector is provided.
USBMI-WP Introduction:
To build a 3G or 4G wireless environment in pit, desert or cave which is a very difficult challenge for constructers as water, dust and sand which are all natural enemies for these delicate electronic devices. Now Bplus Tech. is proud to present a new product USBMI-WP made for waterproof purpose or other extreme conditions. In our internal lab testing, USBMI-WP include antennas and the USB connectors made a kit is designed for most drastic conditions and totally corresponded to the request of IP66 as dust proof, protected from strong water jets. It is suited to oil-mining industry, weather forecasting system, earthquake or volcano monitored system probably located in a very bad environment. So now you don’t need to expense additional cost to add other waterproof-housing to protect your wireless devices. Using our USBMI-WP will be a durable and economic solution for wireless transmission of the most extreme environments.
|
|
Function
- USB mini type-B connection to desktop or notebook PC.
- Support system bus interface: USB.
- Supports USB interface of Mini-Cards such as 3G,CDMA, WLAN,WWLAN, HSPA MODEM , GPS, WiMAX Mini Card to desktop PC..
- Support SIM card connector.
- Support U.FL/IPX to RP-SMA pigtail Wifi RF cable adapter.
|
|
Specification
- PCI Express Mini Card to USB adapter.
- PCI Express Mini Card Electromechanical Specification Revision 1.2
- Universal Serial Bus Specification Revision 2.0
- Full / Half -Mini Card dimension.
- SIM Connector for CDMA HSDPA/HSUPA, UMTS, GSM, GPRS, EDGE
- Access LED.(USBMA)
- Operating Temperature Range : - 40℃ to +85℃
- Operating Humidity Range : 5% to 95% RH
- Compliant with Waterproof IP-66 (USBMI-WP)
|
|
All of Model |
Where to buy? |
Special Information |
USBMI PCBA V1.3b |
Contact Sales |
Support CDMA/LTE module for your OEM project. |
USBMI PCBA-PAD V1.3b |
Contact Sales |
USBMI PCBA with PCB PAD |
USBMI module V1.3b |
Web-shop |
Support CDMA/LTE module for your embedded system |
USBMI-SMA Enclosure V1.3b |
Contact Sales |
USB type MiniCard to USB adapter with SMA connector for 3G/LTE antenna |
USBMI-RPSMA Enclosure V1.3b |
Contact Sales |
USB type MiniCard to USB adapter with RP-SMA connector for Wi-Fi antenna |
USBMI-SMA V1.3b |
Contact Sales |
USB type MiniCard to USB adapter with SMA connector for CDMA/LTE antenna |
USBMI-RPSMA V1.3b |
Contact Sales |
USB type MiniCard to USB adapter with RP-SMA connector for WiFi antenna |
USBMI-WP-SMA V1.3b |
Web-shop |
CDMA/LTE MiniCard to USB adapter with Waterproof Case |
USBMI-WP-RPSMA V1.3b |
Contact Sales |
USB type Wi-Fi MiniCard to USB adapter with Waterproof Case |
USBMI EVK V1.3b |
Contact Sales |
Support CDMA/LTE evaluation kit |
USBMI-OEM |
Contact Sales |
Custom PCBA, Enclosure, RF-Coaxial Cable, USB cable, Screw, Antenna |
|
Web-shop
USBMI PCBA V1.3b
Unit price: USD 41.1 |
|
|
USBMI PCBA V1.3b x1  |
Screw x4
  |
USBMI module V1.3b
Unit price: USD 60. |
|
|
USBMI PCBA V1.3b x1  |
Y05-U04-060
(USB 2.0 A Male to B Mini 5 Pin Cable 60cm) x1
 |
Y05-U17-060
(USB A Male to DC Power Cable) x1
 |
Y05-U02-060
(USB Dupont to 5PIN Cable) x1 |
Screw x2
 |
|
USBMI-WP-SMA V1.3b
Unit price: USD 84. |
|
|
USBMI-WP-SMA V1.3b x1
with RF11008A-WP x2
 |
RF11008A-WP
(
IPX to SMA cable 8cm Water-Proof)
 |
Screw x2
 |
|
USBMI-WH-SMA V1.3b
Unit price: USD 84. |
|
|
USBMI-WH-SMA V1.3b x1
with RF11008A-WP x2
 |
RF11008A-WP
(
IPX to SMA cable 8cm Water-Proof)
 |
Screw x2
 |
|
|
