    MP2M
M.2 Key A Wireless Cardアダプタ







Brief Taiwan 1 Taiwan 2 China
Buy It Now


First Impression


The M.2 Card passive adapter is designed for wireless application on desktop PCs that convert M.2 Wireless Card to USB dupont 5pin or standard PCI-Express 1x slot without fixing bracket.
You can insert your USB type M.2 2230 / 3030 card to this adapter then plug to USB 5pin header port through USB cable.
Or insert your PCI-E type M.2 2230 / 3030 card into this adapter then insert to PCI-E 1x connector.
Also, Wireless & Bluetooth Combo M.2. card such as Intel® Dual Band Wireless-AC 8260 can be used for supporting both Wireless by PCIe and Bluetooth by USB at the same time.


      Specification


  • PCB Dimension: 54 x 23 x 9 mm (L x W x H)
  • Weight: 6 g
  • Operating temperature: 0º to +70° C
  • M.2 Key A or A+E Card to PCI Express adapter
  • Supports system bus interface: PCIe&USB2.0.
  • Supports USB M.2 Card 2230 / 3030 Key A / A+E:
    4G, LTE, 3G,CDMA, WWAN, HSPA, GPS, WiMAX, Bluetooth
  • Support PCIe M.2 Card 2230 / 3030 Key A / A+E:
    IEEE WLAN802.11a/b/g/n, 802.11d, 802.11e, 802.11i, 802.11h, 802.11ac
  • LED: STATUS, POWER, and ALERT#
  • MHF4 to SMA / RP-SMA pigtail Wireless RF cable adapter
  • 4G / LTE / 3G / WiMAX antenna: SMA connector
    WiFi antenna : RP-SMA connector
  • MP2M: Transparent to operating systems and does not require any software drivers



      Notice


  • No driver CD accompanied.
    *Make sure you download and install the Wireless module’s driver before you install the adapter.

Package Content


MP2M
販売価格: USD 40.

MP2M PCBA
(M.2 Key A Wireless Card to Direct PCIe adapter) x1
Y05-U02-060
(USB Dupont to 5PIN Cable) x1
G0030
(Flat-Head M2x1.9 Screw) x1

Buy Related Items


M2P2H
USBM2
