ホーム > 製品情報 > M.2 (NGFF)系製品 > M2P4B

   M2P4B
PCIe 3.0 X4 - M.2 PCIe Gen3 SSD アダプタ







Brief Taiwan 1 Taiwan 2 China
Compatibility List Taiwan 1 Taiwan 2 China
SSD Adapter Selection Guide Taiwan 1 Taiwan 2 China
Web-shop


    概要


M2P4B はデスクトップにPCIeタイプのM.2(NGFF) SSDモジュールをHDDカードとして利用するためのアダプタです。
M.2スロットはKeyMで最大2280サイズ/22mm幅80mm長のモジュールの取り付けが可能で、PCIe Gen3 / 8Gpbsに対応しており最大32Gbpsでのデータ伝送が可能です。

Samsung SM951など、高速M.2 SSDモジュールの利用に最適です。


        機能一覧


  • デスクトップとノートPCにPCIe M.2 SSD をPCIe x4に変換
  • 専用デバイスドライバ不要
    * 一般的にM.2 PCIe SSDは、標準SATA AHCIコントローラおよびそれに接続されたドライブとして認識されます。





        システム要求


  • PCI-E x4スロット



        仕様一覧


  • M.2 SSDをPCIe X4に変換するアダプタ
  • M.2 Specification Revision 1.0準拠
  • M.2カードサイズ: 最大2280 (80mm長)
    2230/2242/2260/2280
  • M.2 Socket 3 PCI-e SSDモジュールサポート
    PCIe Gen3 X4接続
  • M.2モジュール:Key M



    Boot from M.2 SSD storage.


We successfully installed the system through M2P4B Samsung SSD, and the success of the boot.
Operating platform follows:
CPU: Intel® Pentium® Processor G3258
MB: ASROCK Z97 Killer
OS: Windows 8.1 64bit
Adapter : M2P4B
SSD Hard Drive: Samsung XP941-128G M.2(NGFF) PCIe x4 SSD

Most Z97 chipset can support boot with PCIe’s storage.
You can simply install the OS but chose the M.2 storage.
The chose setup BIOS to boot from it.


    Note:
    Because z97’s BIOS is UEFI BIOS, make sure you boot from “UEFI: your storage name”.
  • If you use generic’s USB dongle to install your OS, then you need to choose “UEFI: generic storage”.
  • If you use CD ROM to install your OS, please choose “UEFI: WDC WD10EARS-OOMVMBO”

    Boot selection:





M.2 SSD to PCI-E from factor Adapter Compatibility List

2013Dec13
Gerry Chen
Brand / Model Function Interface Size M2P4A M2P4S M2PS M2P4B Note
Samsung SM951 512GB SSD PCIe key M 2280 Pass Pass NG Pass
Samsung SM951 256GB SSD PCIe key M 2280 Pass Pass NG Pass
Samsung SM951 128GB SSD PCIe key M 2280 Pass Pass NG Pass
Samsung XP941
MZHPU128HCGM-00000
SSD PCIe key M 2280 Pass Pass NG Pass
Samsung XP941
MZHPU256HCGL-00000
SSD PCIe key M 2280 Pass Pass NG Pass
Samsung XP941
MZHPU512HCGL-00000
SSD PCIe key M 2280 Pass Pass NG Pass
Samsung M.2 128G
MZ-NPD1280
SSD SATA key B / M 2280 NG NG Pass NG
Samsung M.2 128G
MZNTD128HAGM
SSD SATA key B / M 2280 NG NG Pass NG
BPLUS M2EM SSD SATA key B / M 2242 NG NG Pass NG
ADATA AXNS341N-64GM-B SSD SATA key B / M 2242 NG NG Pass NG
Sandisk X110 SSD SATA key B / M 2242 NG NG Pass NG
Samsung MZNTD128HAGM SSD SATA key B / M 2280 NG NG Pass NG
Intel
SSD Pro 1500 Series
SSD SATA key B / M 2280
2242
NG NG Pass NG
Intel
SSD 530 Series
SSD SATA key B / M 2280 NG NG Pass NG
Tohsiba THNSNHGDNT SSD SATA key B / M 2280 NG NG Pass NG
LITE-ON L8T-128L6G-HP SSD SATA key B / M 2280 NG NG Pass NG

Brand Function Interface Size M2P4A M2P4S M2PS M2P4B Note
Key M Key M Key B Key M
M2P4A / M2P4S (M.2 Key M)
Designed for PCIE x4 based M.2 (NGFF) SSD module

M2PS (M.2 Key B)
Designed for SATA based M.2 (NGFF) SSD module



    同梱品一覧



M2P4B
販売価格: USD 40.

M2P4B
(PCIe 3.0 X4 - M.2 PCIe Gen3 SSD アダプタ) x1
Y02-D01-060
(Dupont 2PIN Cable) x1
Screw x2




Buy Related Items


PCIe SSD module
M2P4S
M2P4A
