Home > Product > M.2 (NGFF) interface > Samsung PM981 Series
  PM981 Series
(M.2 PCIe Gen3 x4 SSD)


  SAMSUNG M.2 (NGFF) PCIe Gen3 SSD

   PM981 Series (NVMe)

PM981-NVMe-512G
Unit price: USD 260.
PART NUMBER PM981-NVMe-512G
(MZVLW512HAJQ)
Capacity1) 512GB
LBA2) 1,000,215,216

Warranty Policy:
Our web shop follow Samsung Warranty Policy.
The warranted period will be count 12 Months after SAMSUNG production date.
Customer are responsible for the freight shipping back and forth.

Hotfix for windows 8.1
https://support.microsoft.com/zh-cn/kb/2897143

Hotfix for windows 7, server2008 R2
https://support.microsoft.com/en-us/kb/2990941


PM981-NVMe-256G
Unit price: USD 142.
PART NUMBER PM981-NVMe-256G
(MZVLB256HAHQ)
Capacity1) 256GB
LBA2) 500,118,192

Warranty Policy:
Our web shop follow Samsung Warranty Policy.
The warranted period will be count 12 Months after SAMSUNG production date.
Customer are responsible for the freight shipping back and forth.

Hotfix for windows 8.1
https://support.microsoft.com/zh-cn/kb/2897143

Hotfix for windows 7, server2008 R2
https://support.microsoft.com/en-us/kb/2990941



Heat Sink 2x1.5cm
Unit price: USD 2.
Heat Sink 2x1.5cm 5pcs




   PM981 Series (NVMe)


Performance1)
Drive Performance
Parameter Unit Queue Depth 256GB 512GB 1TB 2TB
Sequential Read2)
(Up to)
MB/s QD = 32 TBD 3,000 3,200 TBD
Sequential Write2)
(Up to)
MB/s QD = 32 TBD 1,800 2,400 TBD
Random Read3)
(Up to)
IOPS QD = 1 TBD 12K 12K TBD
IOPS QD = 32 TBD 270K 380K TBD
Random Write3)
(Up to)
IOPS QD = 1 TBD 50K 50K TBD
IOPS QD = 32 TBD 420K 440K TBD
NOTE:
1) Performance measured using CDM 5.0.2 on Windows 10 64bit. Actual performance may vary depending on use conditions and environment.
2) Sequential performance measured using 128KB data size. (QD=32 by Thread=1)
3) Random performance measured using 4KB data size. (QD=32 by Thread 4, QD=1 by Thread 1)
4) Performance measurements based on TurboWrite technology



Power

Maximum Ratings
Parameter Specifications
Supply Voltage Allowable voltage 3.3V ± 5%
Allowable noise/ripple 100mV p-p or less

Power Consumption for M.2 (3.3V Supply)
Parameter Specifications
Power Consumption Active1 (Typical, RMS) Read 5.9W
Write 5.7W
Idle2 (Typical) 30mW
L1.23 (Typical) 5mW
NOTE:
1) Active power is measured on sequential write and read.
2) Idle Power is measured on Idle status with L1.2+APST/ASPM on.
3) If L1.2 time logging option is enabled, L1.2 Power could be 5mW.
4) Active/Idle/L1.2 Power are measured up to 1TB.

MTBF

MTBF is Mean Time Between Failure, and is the predicted elapsed time between inherent failures of a system during operation. As same word,
AFR (annual failure ratio) is 0.4%. MTBF can be calculated as the arithmetic average time between failures of a system.
MTBF Specifications
Capacity MTBF
256GB 1,500,000 Hours
512GB
1TB
2TB


UBER

UBER is Uncorrectable Bit Error Rate.
UBER Specifications
Parameter Specification
UBER < 1 sector per 1015 bits read


Environmental Specification

Temperature, Humidity, Shock, Vibration
UBER Specifications
Parameter Mode Specification
Temperature (Tc) Operating1) 0°C to 70°C
Non-operating -40°C to 85°C
Humidity2) Non-operating 5% to 95%
Shock3) Non-operating 1500G
Vibration4) Non-operating 20G
NOTE:
1) Temperature is measured by SMART Temperature. Proper airflow recommended
2) Humidity is measured in non-condensing
3) Test condition for shock: 0.5ms duration with half sine wave
4) Test condition for vibration: 10Hz to 2000Hz


Physical dimensions and Weight

Parameter Value
Width 22.00 ± 0.15 mm
Length 80.00 ± 0.15 mm
Thickness Max. 2.38 mm
Weight 256/512GB/1/2TB Max 9.0g
