    R2y Series
PCIe x1, x4, x16, M.2 KeyM / A+E, mPCIe (mini PCIe), U.2 (SFF-8639) PCIe extender x16 gen3 ribbon riser card cable twin axial high bandwidh flexible 8Gpbs 164pin adapter jumper



        First Impression


R2y series is PCIe x4 Edge Connector Extension Adapter cable, adapted to PCIe x1, x4, x16, M.2 Key M / A+E, mPCIe (mini PCIe), U.2 (SFF-8639) connectors to re-locate a PCIe card slot or bridge between slots on two different PCBs.

The ribbonized format of the axial cable provides a dense and flexible solution without signal attenuation for high speed PCIe Gen3 8Gbps Data Transaction, bidirectional 256Gbps (256GT/sec) for PCI x16, and 16Gpbs (16GT/sec) per PCIe lane.


R2y Series Comparison Table: Rxy, x=2 , Header = PCIe x4 Edge Connector

Header (x)
x Code= 2

Receptacle (y)
y Code= 1~7

Description

x Code= 2

PCIe x4

Edge Connector



xxx
y Code= 1
R1F / R1R / R1L
PCIe x1 Edge Free
R21 : R21zz-nnn
y=1: PCIe x1
* Edge Free for x4, x8, x16
* zz = SF, SR, SL
R21SF, R21SR, R21SL
y Code= 2
R2F / R2R / R2L
 PCIe x4 Edge Free
* Edge Free for x8, x16     * PCIe x4 connection
R22 : R22zz-nnn
y=1: PCIe x4
* zz = SF, SR, SL, SS
R22SF, R22SR, R22SL, R22SS
y Code= 3
R3F / R3R / R3L

PCIe x16 * PCIe x4 connection     * Retention for zz=SR & SL only
R23 : R23zz-nnn
y=3: PCIe x16
* PCIe x4 connection
* Retention for zz=SR & SL only
* zz = SF, SR, SL
R23SF, R23SR, R23SL
y Code= 4
R4F

M.2 Key M 2280 * PCIe x4 connection
R24 : R24zz-nnn
y=4: M.2 Key M 2280
* PCIe x4 connection
* zz = SF >> R24SF
y Code= 5
R5F
  M.2 Key A E 2230 R25 : R25zz-nnn
y=5: M.2 Key A E 2230
* PCIe x1 connection
* For M.2 Key A or A+E modules
* zz = SF >> R25SF
y Code= 6
R6F
  mPCIe R26 : R26zz-nnn
y=6: mPCIe (mini PCIe)
* PCIe x1 connection
* zz = SF >> R26SF
y Code= 7
R7F
  U.2 (SFF-8639) R27 : R27zz-nnn
y=7: U.2 (SFF-8639)
* PCIe x4 connection
* zz = SF >> R27SF
* zz: Connector Type: Straight (SF), Right angles (SR), Left angled (SL), Dual Edge (SS)
* nnn: Cable Length (cm), Standard nnn=015, 15cm (6 inch)


R2y Series Comparison Receptacle
R1R R1L R1F R2R R2L R2F R3R R3L R3F R4F R5F R6F R2S
Header R2S R21SR R21SL R21SF R22SR R22SL R22SF R23SR R23SL R23SF R24SF R25SF R26SF R22SS
R2F           R22FF



Header: R2S
Receptacle: R2R
Part Number: R22SR



        Specification


  • Maximum Speed:
    PCIe Gen3 8Gbps. Bidirectional 2.0GB/sec (16Gpbs , 16GT/sec) per PCIe lane, PCIe Gen2 (5Gbps) & PCIe Gen1 (2.5Gbps) compatibles.
  • Header (Male) Connector: PCIe x4
  • Receptacle (Female) Connector:
    PCIe x1, x4, x16, M.2 Key M / A+E, mPCIe (mini PCIe), U.2 (SFF-8639)
  • Cable: Length:
    Standard (015) = 15cm (6inch), Customized for 1~999cm (001~999)
    * Guideline: PCIe Gen3 8Gbps max 24 inch (60cm)
  • Cable Type:
    Flat, Twin Axial, Thickness=1.4mm (1/16 inch) Width=54mm (9mm*6, 2 1/8 inch)
  • Color: Black
  • Connector Type:
    Straight (SF), Right angles (SR), Left angled (SL), Dual Edge (SS)

        Bullet Points


  • Cable Quality:
    Stable PCIe Gen3 8Gbps or higher with high quality Axial Cable
  • Cable Flexibility:
    Highly-routable, foldable, flexible
    Thickness=1.4mm (1/16 inch) Width=9mm (3/8 inch)
  • Cable Length:
    Standard (015) = 15cm (6inch), Customized for 1~999cm (001~999)
    * Contact sales for customize: sales@bplus.com.tw
  • PCB Quality:
    Experienced design and durable material for High frequency and low attenuation.
  • Connector Quality:
    Taiwan Made high quality for PC server / mother board.
  • Solder Point Protection:
    PCB-Swaddled and fixed with Bolts and nut to prevent tearing and short circuit for PCB-Cable solder points.

Web-shop


R22SR-050A     Unit price: USD 44.
R22SL-050A     Unit price: USD 44.
R22SF-050A     Unit price: USD 44.
MOQ 50pcs   Contact Sales
PCIe x1
R21SF-xxx
MOQ 50pcs   Contact Sales
PCIe x4
R21SR-xxx
MOQ 50pcs   Contact Sales
PCIe x16
R23SR-xxx
MOQ 50pcs   Contact Sales
M.2 Key M 2280
R24SF-xxx
MOQ 50pcs   Contact Sales
M.2 Key A E 2230
R25SF-xxx
MOQ 50pcs   Contact Sales
mPCIe (mini PCIe)
R26SF-xxx
MOQ 50pcs   Contact Sales
U.2 (SFF-8369)
R27SF-xxx
MOQ 50pcs   Contact Sales
PCIe x4 Jumper
R22SS-xxx
MOQ 50pcs   Contact Sales
PCIe x4 Jumper
R22FF-xxx





Buy Related Items


R1y Series
R3y Series
R4y Series
R5y Series

Customized Rxy Series Extender Board

Series Product # Header (x) =1~7 Receptacle (y) = 1~7
R1y R1yzz-nnn 1: PCIe x1 1: PCIe x1 Edge Free for x4, x8, x16

2: PCIe x4 Edge Free for x8, x16

3: PCIe x16

4: M.2 Key M

5: M.2 Key A+E

6: mPCIe (mini PCIe)

7: U.2 (SFF-8639)
R2y R2yzz-nnn 2: PCIe x4
R3y R3yzz-nnn 3: PCIe x16
R4y R4yzz-nnn 4: M.2 Key M
R5y R5yzz-nnn 5: M.2 Key A+E
R6y R6yzz-nnn 6: mPCIe (mini PCIe)
R7y R7yzz-nnn 7: U.2 (SFF-8639)

PCIe-Cable Adapter part-number and product name example:

R11SF020A    PCIe 1x Extender cable=20cm
R22SS050A    PCIe 4x Jumper cable=50cm
R33SR030A   PCIe 16x Right Angle Adapter cable=30cm
R47SF015A  U.2 NVMe SSD to M.2 Key M Adapter cable=15cm
Rxy Series Comparison Header (Gold finger)
R1S R2S R3S R4S R5S R6S R1F R2F R3F
R1R R11SR R21SR R31SR R41SR R51SR R61SR
R1L R11SL R21SL R31SL R41SL R51SL R61SL
R1F R11SF R21SF R31SF R41SF R51SF R61SF R11FF
R2R R12SR R22SR R32SR R42SR R52SR R62SR
R2L R12SL R22SL R32SL R42SL R52SL R62SL
R2F R12SF R22SF R32SF R42SF R52SF R62SF   R22FF
R3R R13SR R23SR R33SR R43SR R53SR R63SR
R3L R13SL R23SL R33SL R43SL R53SL R63SL
R3F R13SF R23SF R33SF R43SF R53SF R63SF     R33FF
R4F R14SF R24SF R34SF R44SF R54SF R64SF
R5F R15SF R25SF R35SF R45SF R55SF R65SF
R6F R16SF R26SF R36SF R46SF R56SF R66SF
R7F R17SF R27SF R37SF R47SF R57SF R67SF
R1S R11SS
R2S   R22SS
R3S     R33SS


Header: R1S
Receptacle: R1R
Part Number: R11SR
