  M.2 (NGFF) PCIe SSD
(NAND based Solid State Drive)



  SAMSUNG M.2 (NGFF) PCIe Gen2 SSD


   XP941 Series

  PART NUMBER Capacity1) Photo
MZHPU128HCGM 128GB
MZHPU512HCGL 512GB

保固政策:
我們販售的XP941系列SSD依循Samsung的保固原則。
提供自購買日起6個月內的保固,
客戶需自行負擔商品寄送來回的運費。


FEATURES Environmental Specifications
  • 64Gb MLC NAND Flash Memory Temperature)
  • Up to 512MB LPDDR2 DRAM Buffer Memory
  • PCIe Gen2 interface, up to 4 lanes
  • Support Standard AHCI driver
  • Support Toggle2.0 interface
  • End-to-End Data Protection
  • Support TRIM Command
  • RoHS Compliant Vibration
  • Halogen-Free Compliance
    Temperature3)
  • Operating 0°C to 70°C
  • Non-operating -40°C to 85°C
    Humidity (non-condensing)
  • Non-operating 5 ~ 95 %
    Linear Shock (1/2 sine pulse)
  • Non-operating, 0.5ms 1,500 G
    Vibration (random, 7~800Hz, 15min/axis, 3axis)
  • Non-operating 3.08Grms

Drive Configuration Electrical Specifications
  • From Factor: M.2
  • Interface: PCIe Gen2 5Gb/s, up to 4 lanes
  • Bytes per Sector: 512 Bytes
  • Supply Voltage: +3.3V ± 5%
  • Voltage Ripple/Noise (max.): 100mV p-p
  • Active (typical): 5.8 W
  • Idle (typical): 80 mW

Performance Specifications Physical Dimension
    Data Transfer Rate(128KB)2)
  • Sequential Read: Up to 1170 MB/s
  • Sequential Write: Up to 930 MB/s
    Data I/O Speed(4KB)2)
  • Random Read (QD=32): Up to 122K IOPS
  • Random Write (QD=32): Up to 72K IOPS
  • Width: 22.00 ± 0.15 mm
  • Length: 80.00 ± 0.15 mm
  • Height: Max 3.73 mm
  • Weight
    128/256GB: Max. 8g
    512GB: Max. 8.5g

Reliability Specifications Specifications are subject to change without notice.
  • UBER: < 1 sector per 1015 bits read
  • MTBF: 1.5 Million Hours

1) 1MB = 1,000,000 Bytes, 1GB = 1,000,000,000 Bytes, Unformatted Capacity.

2) Performance measured with IOMeter. Actual performance may vary depending on
use conditions and environment.

3) Case Temperature
